Heavy expanded metal mesh

Read More About heavy duty expanded steel mesh

Expanded steel mesh is a metal screen, also known as expanded metal mesh, diamond mesh, iron mesh, expanded metal mesh, heavy steel mesh, foot mesh, aluminum mesh, stainless steel mesh, granary mesh, antenna mesh, filter mesh, and audio mesh wait.

Send Email To Us Download To PDF

Product Detail

Product Tags

Product Introduction
Material: low carbon steel plate, stainless steel plate, aluminum plate, copper plate, nickel plate, magnesium plate, aluminum-magnesium alloy plate and other metal plates.

Surface treatment: PVC dipping (plastic spraying, plastic coating), hot-dip galvanizing, electro-galvanizing, anodizing (aluminum plate), anti-rust paint spraying, etc.

Classified by material: low carbon steel sheets, aluminum plates, stainless steel plates, aluminum-magnesium alloy plates, steel plates, and other plates.

Classified by use: widely used in highways, railways, civil buildings, water conservancy and other construction, various machinery, electrical appliances, window protection and aquaculture, etc. Products with various special specifications can be processed and customized according to customer requirements.

Classified by hole type
1. Fish scale hole steel aluminum metal mesh
2. Hexagonal hole steel and aluminum metal mesh
3. Fancy steel and aluminum metal mesh
4. Turtle-shaped steel and aluminum expanded metal mesh

Classified by hole type
1. Fish scale hole steel aluminum metal mesh
2. Hexagonal hole steel and aluminum metal mesh
3. Fancy steel and aluminum metal mesh
4. Turtle-shaped steel and aluminum expanded metal mesh

WHAT IS EXPANDED METAL?
Expanded Metal is a rigid, non-raveling piece of metal that has been slit and expanded. In the expanding process, metal can be expanded ten times its original size, and lose up to 80% of its weight, becoming stronger and more rigid. No material is lost in the manufacturing process.

EXPANDED METAL TERMINOLOGY

S.W.M = Short way of Mesh:
This is the size measured across the short way of the diamond mesh from center to center of the joints.

L.W.M = Long way of Mesh:
This is the size measured across the long way of the diamond mesh from center to center of the joints.

Strand Width:
The size of the strand is measured at right angles to its thickness.

Strand Thickness:
The thickness of the sheet before the expanding process takes place.

Product Parameters

Material	Stainless Steel, Low Carbon Aluminum, Low carbon steel, Galvanized steel, Stainless steel, Copper, Titanium etc
LWD	MAX 300mm
SWD	MAX 120mm
Stem	0.5mm-8m
Sheet width	MAX 3.4m
Thickness	0.5mm - 14mm
SurfaceTreatment	- Without treatment is ok - Anodized (color can be customized) - Powder coated - PVDF - Spray painted - Galvanized: Electric galvanized, Hot-dipped galvanized
Classification	- Small expanded wire mesh - Medium expanded wire mesh - Heavy expanded wire mesh - Diamond expanded wire mesh - Hexagonal expanded wire mesh - Special expanded
Use	Expanded metal mesh can be widely used in the protection of machinery equipment, handicraft manufacturing, shelves, heavy machinery, work platforms, walkways, ships as well as other areas.
